date：2025-12-01
December 1st, 2025, Changchun, China–Gpixel announces the launch of the GMAX2424BSI, a 24 MP rolling shutter, backside illuminated CMOS image sensor with global reset supporting both MIPI and LVDS output. Compared to previous generations of image sensors, the GMAX2424BSI provides higher dynamic range, faster frame rates, higher NIR sensitivity and lower cost integration options enabled by MIPI. The sensor is footprint-compatible with two other sensors from Gpixel’s MIPI portfolio, GMAX3405 and GMAX3412, providing a 5 MP, 12 MP and 24 MP family solution.
The GMAX2424BSI is a state-of-the-art rolling shutter CMOS image sensor delivering 6016 (H) × 4096 (V) pixel resolution in a C-mount compatible 1.1″ optical format. Leveraging advanced 2.4 μm Back-Side Illuminated (BSI) pixel technology, the sensor maximizes light sensitivity and angular response while maintaining exceptional image quality. It supports dual ADC modes and both LVDS and MIPI outputs for versatile operation. In 12 bit mode, the sensor achieves 73 dB dyanimic range with 2.7 e⁻ readout noise and 12.1 ke⁻ full well capacity and delivers 30 fps utilizing 10 channels of sub-LVDS. For low-light applications, the sensor can be operated with l6x gain,reducing the readout noise to 1.3 e⁻. In 10 bit mode over 14 channels sub-LVDS, 60 fps can be achieved. For applications requiring lower cost system designs, the sensor delivers 17 fps over 4 MIPI channels. GMAX2424BSI supports multiplexing over both the sub-LVDS and MIPI channels for further system simplication.
Figure 1. The GMAX2424BSI is a 1.1” 24 MP BSI image sensor with MIPI and LVDS output.
The sensor’s advanced BSI technology provides excellent sensitivity with a peak quantum efficiency of 92% at 510 nm and 35% at 800 nm. Low power mode and global reset further enhance adaptability across diverse imaging scenarios. Color and monochrome variants of the sensor are packaged in a 176 pins LGA package (22.93 mm × 19.39 mm), combining high reliability with efficient thermal management and ensuring stable performance in demanding environments. Power consumption less than 0.61 W further enables compact and efficient camera and module designs.
Figure 2. The GMAX2424BSI reaches a peak QE of 92% at 510 nm and 35% QE at 800 nm.
Designed for high-end industrial, scientific and medical applications, the sensor excels in tasks requiring high-performance and high-resolution in a compact and cost-effective imaging system. With the addition of GMAX2424BSI, Gpixel’s portfolio of image sensors supporting MIPI in addition to LVDS output now covers resolutions from 2.5 MP to 24 MP for ISP-based, embedded, and edge compute system solutions.
Engineering samples and evaluation systems are available now. Contact info@gpixel for inquiries.
About Gpixel
Gpixel is an international company providing high-end customized and off the-shelf CMOS image sensor solutions for industrial, medical, scientific, and professional imaging applications. Gpixel’s standard products include the GMAX and GSPRINT fast frame rate sensors, the GSENSE high-end scientific CMOS image sensor series, the GLUX series of high sensitivity sensors for surveillance, the GL series of line scan imagers, the GLT series of TDI imagers, GTOF series of iTOF imagers, and the GCINE series of sensors for professional video and photography. Gpixel provides a broad portfolio of products leveraging the latest technologies to meet the ever-growing demands of the professional imaging market.
